Embedded Devices

Our embedded devices integrate sensor and actuator interfaces into your processes via the network and come in a rugged industrial enclosure. Their performance is scalable across a wide range, from simple remote I/O devices to high-performance Linux-based systems.

Other products:

Hardware & Design

Fanless operation for industrial applications
Galvanic isolation of all I/Os (analog, digital, interfaces) from one another and from the device
I/Os can be used directly in the process

Communication & Power Supply

Based on eNetMini and eNetMaxi embedded modules
Data communication via TCP, UDP, and HTTP
Power supply via Ethernet (PoE, IEEE 802.3af) possible
Alternative: conventional power supply
Planned power-line solution via 240V home wiring (power + data)

eNetVario.

eNetVario is a compact, rugged embedded system for industrial applications with flexible I/O expansion and support for up to 24 sensors/actuators. Thanks to Debian Linux and pre-installed MQTT (Mosquitto) and Node-RED, it is ready for immediate use. Communication takes place via TCP/IP, MQTT, or REST—securely encrypted using TLS. Power is supplied simply via PoE, making installation and operation particularly efficient.

Overview

Hardware

Compact, rugged metal housing (industrial use)
Desktop unit or DIN rail mounting (EN 60715)
2× Ethernet (10/100), USB, and serial interfaces
Expandable: up to 6 I/O modules (max. 24 sensors/actuators)

Software

Debian Linux (hardware-optimized)
Pre-installed: Mosquitto (MQTT) & Node-RED
Communication: TCP/IP, MQTT, JSON-REST API

Power Supply
PoE (IEEE 802.3af) via Ethernet
Optional traditional power supply available

Features & Networking

M2M communication & edge/cloud connectivity
Integration of external sensors/actuators (e.g., remote I/O)
Two networks can be separated (segment isolation)
Encryption via TLS

Concept

Combination of I/O + intelligent preprocessing
Flexible for many industrial applications
Development & Customization
Developed & manufactured in Wuppertal
Customization available (firmware, design, OEM solutions)

Advantage

Easy installation (Ethernet + PoE only)
Cost-effective, flexible, ready for immediate us

Technical Specifications

Dimensions
- D: 133 mm, H: 44 mm, W: 133 mm
Protection class: IP20
Ambient temperature:
- Operating: 0 … 50°C
- Storage: -40 … +80°C
Cooling via natural convection (no fan)
Relative humidity: 0 … 90%, non-condensing
Power supply via Power over Ethernet (PoE, IEEE802.3af)
Alternatively, external power supply (18–48 V DC)

The base unit ‘11’ consists of a modified Interscale enclosure from Schroff in which the eNetEval.1502 is installed along with an eNetMaxi.STD module.

MKC1502.STD carrier board
- 2 serial interfaces (USB, FTDI)
- 2 100 Mbit network ports (RJ45, PoE)
- uSD card slot
- USB master (Type A connector)
- USB OTG (microUSB-AB)
- LED status indicators
- Sensor for temperature and relative humidity

eNetMaxi.STD module
- ARM Cortex-A8, 1 GHz
- 512 MB DDR3 RAM
- 4 GB eMMC flash
- 1 MB SPI flash
- 16-bit GPMC bus
- Timers, interrupts
- RTC, watchdog

The following table shows the matrix of available processor I/O, according to which the optional expansions can be combined as desired.

Prozess I/O Matrix					Data sheet
Extension ‘b’	2	2	–	–
Extension ‘i’	2	–	2	–

Order Numbers

On this page you will find all eNetvario devices that have already been ordered and used by our customers. If the combination of process I/O you require is not listed, we will be happy to make you an offer for your individual device.

Prices in EURO plus VAT and shipping for commercial users. Please understand that we only deliver goods to new customers against prepayment.

	Prozess E/A	Order number
eNetVario without I/O	–	Vario-11–
eNetVario with I/O	12 digital inputs (12–230 V AC/DC) 4 digital outputs (relays, normally open contacts)	Vario-11-bbiiii
SD Cards	System SD Card for eNetVario	0090_PHD

Downloads

Explanations regarding the communication and parameterization of our devices, the JSON-REST API used, and a description of the homepage can be found directly in our online documentation.

You can download manuals, data sheets, instructions, and the latest software/firmware further down on this page.

Product description

Data sheet (DE)

Data Sheet Extension ‘b’ (DE)

Data Sheet Extension ‘i’ (DE)

0090 PHD Manual (DE)

Manual-MKC-1502 (DE)

Software Manual eNetMaxi-2 (DE)

Software Manual VM Linux (DE)

Technical Manual eNetMaxi-2v (DE)

Technical Manual eNetVario (DE)

eNetIO.

MKC | Development | Assembly: in-house | IOnet-4

eNetIO is a rugged, DIN-rail-mounted remote I/O device with flexible analog and digital interfaces. It supports up to 30 sensors/actuators and communicates via MQTT or REST over TCP/IP. Power is conveniently supplied via PoE—with no additional cabling required. Direct operation within your own network, without the cloud, ensures maximum data security and flexibility.

Overview

Remote I/O device for industrial applications
Rugged housing, DIN rail mounting (EN 60715) or flexible installation
Variants (-1, -2, -4, -8) for different requirements
Up to 30 sensors/actuators can be connected
Communication via TCP/IP, MQTT, and JSON-REST API
Integrated web interface for configuration (customizable)
Operates without a cloud or app → maximum data security
Power supply via PoE (IEEE 802.3af)
Easy installation with just one Ethernet cable
Ideal for decentralized measurement and control applications
Developed & manufactured in Wuppertal
Customizable (firmware, design, OEM solutions)

Technical Specifications

The devices are available in four different housing variants for DIN rail mounting in accordance with EN 60 715.

Dimensions
- eNetIO-1: D: 90 mm, H: 60 mm, W: 17.5 mm
- eNetIO-2: D: 90 mm, H: 60 mm, W: 35.0 mm
- eNetIO-4: D: 90 mm, H: 60 mm, W: 70.0 mm
- eNetIO-8: D: 90 mm, H: 60 mm, W: 140.0 mm

Ambient Temperature:
- Operating: 0 … 50°C
- Storage: -40 … +80°C

Process I/O galvanically isolated
Cooling via natural convection (no fan)
Relative humidity: 0 … 90%, non-condensing
Power supply via Power over Ethernet (PoE, IEEE802.3af)
Alternatively, external power supply (18–48 V DC)
Network via RJ45
- Web server (HTTP)
- Measurement data transmission (MQTT, JSON REST API)

The following table lists all eNetIO devices that our customers have already ordered and are currently using. If the process I/O combination you are looking for is not listed, we recommend that you consult the technical manual.

Devices
eNetIO-1-a	1	1	–	–
eNetIO-2-ab	3	3	–	–
eNetIO-2-ac	5	1	–	–
eNetIO-2-ad	1	5	–	–
eNetIO-2-ah	1	1	4	–
eNetIO-2-ai	3	1	2	–
eNetIO-2-aj	1	1	–	2
eNetIO-4-abbb	7	7	–	–
eNetIO-4-accc	13	1	–	–
eNetIO-4-addd	1	13	–	–
eNetIO-4-ahhh	1	1	12	–
eNetIO-4-aiii	7	1	6	–
eNetIO-4-ajjj	1	1	–	6
eNetIO-8-abbbbbbb	15	15	–	–
eNetIO-8-accccccc	29	1	–	–
eNetIO-8-addddddd	1	29	–	–

Order Numbers

On this page, you will find all eNetIO devices that our customers have already ordered and are currently using. If the combination of process I/O you are looking for is not listed, we recommend consulting the technical manual. We would be happy to provide you with a quote for your custom-configured device.

Prices available upon request. Please understand that we only ship to new customers upon receipt of payment in advance.

Device / Order Number	Galvanically Isolated Process I/O
eNetIO-1-a	1 digital output (relay, normally open contact) 1 digital input (12–230 V AC/DC)
eNetIO-2-ab	3 digital outputs (relay, normally open) 3 digital inputs (12–230 V AC/DC)
eNetIO-2-ac	1 digital output (relay, normally open contact) 5 digital inputs (12–230 V AC/DC)
eNetIO-2-ad	5 digital outputs (relays, normally open contacts) 1 digital input (12–230 V AC/DC)
eNetIO-2-ah	1 digital output (relay, normally open contact) 1 digital input (12–230 V AC/DC) 4 current inputs (0–25 mA)
eNetIO-2-ai	1 digital output (relay, normally open contact) 3 digital inputs (12–230 V AC/DC) 2 current inputs (0–25 mA)
eNetIO-2-aj	1 digital output (relay, normally open contact) 1 digital input (12–230 V AC/DC) 2 current outputs (0–20 mA)
eNetIO-4-abbb	7 digital outputs (relays, normally open contacts) 7 digital inputs (12–230 V AC/DC)
eNetIO-4-accc	1 digital output (relay, normally open contact) 13 digital inputs (12–230 V AC/DC)
eNetIO-4-ddd	13 digital outputs (relays, normally open contacts) 1 digital input (12–230 V AC/DC)
eNetIO-4-ahhh	1 digital output (relay, normally open contact) 1 digital input (12–230 V AC/DC) 12 current inputs (0–25 mA)
eNetIO-4-aiii	1 digital output (relay, normally open contact) 7 digital inputs (12–230 V AC/DC) 6 current inputs (0–25 mA)
eNetIO-4-ajjj	1 digital output (relay, normally open contact) 1 digital input (12–230 V AC/DC) 6 current outputs (0–20 mA)
eNetIO-8-abbbbbbb	15 digital outputs (relays, normally open contacts) 15 digital inputs (12–230 V AC/DC)
eNetIO-8-accccccc	1 digitaler Ausgang (Relais, Schließer) 29 digitale Eingänge (12..230V AC/DC)
eNetIO-8-addddddd	29 digital outputs (relays, normally open contacts) 1 digital input (12–230 V AC/DC)

Downloads

Information about communication and configuration of our devices, the JSON-REST API we use, and a description of the website are available directly in our online documentation.

You can download manuals, data sheets, instructions, and the latest software/firmware below.

Installation (DE)

eNetIO technical manual

Product description

Data sheets:

Quick Start Guide:

License

The software components used in the eNetMini module are subject to certain licenses. The components used and their associated licenses are listed below.

MKC

The widely used MIT license is used for the software created by MKC Michels & Kleberhoff. This applies both to the finished, closed-source application of the module and to the freely accessible (open-source) source code, which is available as examples for your own applications.

Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the “Software”), to deal in the Software without restriction, including without limitation the rights to use, copy, modify, merge, publish, distribute, sublicense, and/or sell copies of the Software, and to permit persons to whom the Software is furnished to do so, subject to the following conditions:

The above copyright notice and this permission notice shall be included in all copies or substantial portions of the Software.

THE SOFTWARE IS PROVIDED “AS IS”, WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE.

TI-RTOS

Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.
Neither the name of Texas Instruments Incorporated nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission.

THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT OWNER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

eNetCube.

eNetCube enables reliable data acquisition and control of sensors and actuators in environments up to IP55. Thanks to modular eNetMini technology, the system is flexibly expandable and versatile. Communication takes place via MQTT or REST over TCP/IP—simply and securely. PoE power supply and cloud-free operation ensure maximum efficiency and data security.

Overview

Flexible system for data acquisition, control, and monitoring of sensors/actuators
Suitable for demanding environments up to IP55
Modular design with eNetMini modules for custom interfaces
Communication via TCP/IP, MQTT, and JSON-REST API
Integrated, customizable web interface for configuration
Operates without a cloud or app → high data security
Power supply via PoE (IEEE 802.3af)
Easy installation with just one Ethernet cable
Flexible mounting: DIN rail, desktop unit, or tripod (1/4″)
Ideal for decentralized measurement and control solutions
Utilizes existing network infrastructure
Developed & manufactured in Wuppertal
Customizable (firmware, design, OEM systems)

Technical data

The housing is designed so that the device can be operated with a stand as a desktop device, for top-hat rail mounting in a switch cabinet in accordance with EN 60 715 or on a wall bracket with a 1/4″ inch thread.

Dimensions
- D: 91 mm, H: 42 mm, W: 47.2 mm
- IP55: D: 106 mm, H: 42 mm, W: 47.2 mm
Protection class: IP55
Ambient temperature:
- Operating: 0 … 50°C
- Storage: -40 … +80°C
Process I/O galvanically isolated

Cooling via natural convection (no fan)
Relative humidity: 0 … 90%, non-condensing
Power supply via Power over Ethernet (PoE, IEEE802.3af)
Netzwerk auf RJ45
- Web-Server (HTTP)
- Messwertübertragung (MQTT, JSON REST API)

Device	Protection class	galvanically isolated process I/O
eNetCube-01-01-01	–	2 digital outputs (relay, normally open contact)
eNetCube-01-02-02	IP55	2 digital outputs (relay, normally open contact)
eNetCube-02-01-01	–	2 digital inputs (12…230V AC/DC)
eNetCube-02-02-02	IP55	2 digital inputs (12…230V AC/DC)
eNetCube-03-01-03	–	Motion sensor
eNetCube-03-02-03	IP55	Motion sensor

Order numbers

All eNetCube devices are listed on this page. If the combination of process I/O you require is not listed, we will be happy to make you an offer for your individual device.

Prices in EURO plus VAT and shipping for commercial users. Please understand that we only deliver goods to new customers against prepayment.

Device / Order number	Protection class	galvanically isolated process I/O
eNetCube-01-01-01	–	2 digital outputs (relay, normally open contact)
eNetCube-01-02-02	IP55	2 digital outputs (relay, normally open contact)
eNetCube-02-01-01	–	2 digital inputs (12…240V AC/DC)
eNetCube-02-02-02	IP55	2 digital inputs (12…240V AC/DC)

Downloads

The explanations about the communication and parameterization of our devices, the JSON-REST API used and the description of the homepage are available directly in our online documentation.

Manuals, data sheets, instructions and the latest software/firmware can be downloaded below.

Product description

License

The software components used in the eNetMini module are subject to certain licenses. The components used and their associated licenses are listed below.

MKC

The widely used MIT license is used for the software created by MKC Michels & Kleberhoff. This applies both to the finished, closed-source application of the module and to the freely accessible (open-source) source code, which is available as examples for your own applications.

Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the “Software”), to deal in the Software without restriction, including without limitation the rights to use, copy, modify, merge, publish, distribute, sublicense, and/or sell copies of the Software, and to permit persons to whom the Software is furnished to do so, subject to the following conditions:

The above copyright notice and this permission notice shall be included in all copies or substantial portions of the Software.

THE SOFTWARE IS PROVIDED “AS IS”, WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE.

TI-RTOS

Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.
Neither the name of Texas Instruments Incorporated nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission.

THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT OWNER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

eNetMini.

eNetMini is a compact single-board solution for sensors and actuators—flexible enough for use in both industrial and smart home applications. It can operate standalone or be integrated into systems such as Node-RED or openHAB. Communication takes place via MQTT or REST over TCP/IP—simple and efficient. Thanks to PoE and cloud-free operation, fast, secure integration is guaranteed.

Overview

Compact single-board computers for connecting sensors and actuators
Can be used standalone or in existing control systems
Suitable for industrial and smart home applications (e.g., Node-RED, openHAB)
Communication via TCP/IP, MQTT, and JSON-REST API
Integrated, customizable web interface for configuration
Operates without a cloud or app → maximum data security
Power supply via PoE (IEEE 802.3af)
Easy installation via an Ethernet cable
Optional enclosure or customizable via 3D printing
3D data and resources available via GitHub
Ideal for decentralized measurement and control solutions
Developed and manufactured in Wuppertal
Customizable (firmware, design, OEM systems)

eNetMini.2105

The different versions of the eNetMini.2105 device provides you with a lot of onboard environmental sensors.
It’s using the Bosch Sensortec and TI family environmental sensors, to integrate high linearity and high accuracy sensors for gas, pressure, humidity, temperature and ambient light.
To detect changes in infrared radiation which occur when there is movement by a person (or object) which is different in temperature from the surroundings the device uses an Panasonich passive infrared sensor.

The voltages required in the device are extra-low voltage (<60 volts DC). For this reason, contact protection is not required. However, should this be necessary, the use of the optional housing may be an option. If you are not satisfied with the form and function of the case, you will find all the data you need to modify and print it on Github.

Possible use cases are:

Personal air quality tracker
Air quality mapping
Enhanced context awareness
Indicator of too high / low humidity
Air quality & well-being indicator
Sleep / recovery tracker
Weather trend
Stair counter
Floor level detection
Motion detection
Ambient light tracking

Technical data

Device	alvanically isolated process I/O	Data Sheet	Quick guide
eNetMini-2105-1	Magnetic switch, Ambient light, Pressure, Temperature, Humidity, Motion detector

Order numbers

On this page, you will find all eNetMini devices. If the combination of process I/O you are looking for is not listed, we would be happy to provide you with a quote for a custom device.

Prices are available upon request. Please understand that we only ship goods to new customers upon receipt of payment in advance.

Device / Order Number	galvanically isolated process I/O
eNetMini 2105-1	Magnetic switch, Ambient light, Pressure, Temperature, Humidity, Motion detector
Magnet	Ferrite Y35 ring magnet (Ø20×5.5mm, inner diameter Ø6.5)
Housing eNetMini-2105	Three-part housing with housing base, housing cover and an individual sensor cover

Downloads

The explanations about the communication and parameterization of our devices, the JSON-REST API used and the description of the homepage are available directly in our online documentation.

Manuals, data sheets, instructions and the latest software/firmware can be downloaded below.

Product description

MANUALS:

Installation-eNetMini.2105 (DE)

Technical Manual-eNetMini.2105 (DE)

DATA SHEET:

eNetMini.2105

Quick guide:

eNetMini.2105

Licence

The software components used in the eNetMini module are subject to certain licenses. The components used and their associated licenses are listed below.

MKC

The widely used MIT license is used for the software created by MKC Michels & Kleberhoff. This applies both to the finished, closed-source application of the module and to the freely accessible (open-source) source code, which is available as examples for your own applications.

Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the “Software”), to deal in the Software without restriction, including without limitation the rights to use, copy, modify, merge, publish, distribute, sublicense, and/or sell copies of the Software, and to permit persons to whom the Software is furnished to do so, subject to the following conditions:

The above copyright notice and this permission notice shall be included in all copies or substantial portions of the Software.

THE SOFTWARE IS PROVIDED “AS IS”, WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE.

TI-RTOS

Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.
Neither the name of Texas Instruments Incorporated nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission.

THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT OWNER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

Useful Information.

Node-RED

Node-RED is a flow-based development tool that enables the development of applications in a graphical environment. To simplify access to our devices, we provide you with a Node-RED extension.

You can either install it directly in the Node-RED Editor or download it via GitHub and install it manually.

App MKC-Connect

MKC – Connect is your go-to tool for effortlessly discovering and managing MKC devices on your network. Designed for ease of use, MKC – Connect automatically scans your local network to identify all available MKC devices. Once detected, simply tap to open the device’s webpage directly from the app.

MKC | Development | Assembly: in-house | MKC-Connect Apple Store

MKC-Connect at App-Sore

MKC | Development | Assembly: in-house | MKC-Connect on Google Play

MKC-Connect at Google Play

Online Documentation

We provide explanations regarding communication and parameterization of our devices, the JSON-REST API we use, and a description of the homepage directly in our online documentation.
